Capacities and Work Area
Max workpiece swing/diameter: 610 mm (up to 660 mm with B-axis at 90°)
Max turning length: 1,540 mm
Bar work capacity: 65 mm (standard) up to 91 mm (optional configurations
Spindle Specifications
Main/Sub-spindle speed: 5,000 RPM
Spindle taper/nose: JIS A2-6
Tool spindle (B-axis) speed: 12,000 RPM
Tool spindle travel (X / Y / Z): 495 mm / 250 mm / 1,560 mm
Tooling and Turret
Tool storage capacity: 38 standard, up to 76 tools (optional magazine)
Tool shank type: Capto C6 (or BT40 / HSK-A63)
Lower turret stations: 10 stations (on SZM/SZ configurations)
Machine Location: Korea
