X-axis travel: 4,100 mm
Y-axis travel: 2,200 mm
Z-axis travel: 900 mm (standard) / 1,100 mm (optional)
Table size: 4,000 x 2,100 mm
Max table load: 17,000 kg (17 tons)
Distance between columns: 2,300 mm
Spindle nose to table surface: 200 to 1,100 mm
Spindle taper: BT50 (CAT 50 optional)
Spindle speed: 6,000 RPM standard (gear/roller type), up to 8,000 or 10,000 RPM optional
Spindle motor output: 22 / 26 kW (continuous/30 mins); higher options available
Rapid traverse (X / Y / Z): 15 / 20 / 15 m/min
Guideways: Roller type linear guideways on X and Y axes
Controller: Fanuc CNC system (commonly Fanuc 31i-MB)
Machine Location: Korea
