Axis Travels and Work Area
X-Axis (Longitudinal): 2,200 mm – 4,000 mm
Y-Axis (Cross): 2,500 mm
Z-Axis (Vertical): 1,100 mm – 1,300 mm
Feed Rate (X/Y/Z): Up to 40,000 mm/min
Spindle and Performance
Max Spindle Speed: 18,000 rpm (up to 22,000 rpm options)
Spindle Power: 22 kW / 33 kW (S1/S6 configurations)
Tool Taper: HSK-A63 (DIN 69893)
Tooling and Equipment
Tool Taper: HSK-A63
Automatic Tool Changer (ATC): 60 to 120 station capacity
Max Tool Weight: 10 kg
Max Tool Length: 600 mm
Coolant & Chip Management: Internal/external coolant supply with multi-way chip conveyors.
Machine Location: Korea
