Axis Travels & Work Area
X-axis travel: 8,250 mm (324.8 inches)
Y-axis travel: 3,700 mm (145.6 inches)
Z-axis travel: 1,000 mm (39.4 inches)
W-axis travel (Crossrail): 1,100 mm to 1,450 mm
Distance between columns: 3,200 mm (126 inches)
Table size: 2,700 x 8,100 mm (106.3 x 315 inches)
Maximum table load: 40,000 kg (88,000 lbs)
Spindle & Performance
Spindle taper: BT 50 / ISO 50
Spindle speed: 4,000 rpm (gear-driven type)
Spindle motor power: 37 kW / 49 HP
Rapid traverse (X / Y / Z): 16 m/min / 16 m/min / 10 m/min
Tooling & Physical Size
Tool magazine capacity: 60 stations (standard/optional variations)
Ram dimensions: 380 x 380 mm
Machine weight: Approx. 94,000 kg (207,234 lbs)
CNC Control: Fanuc 31iB / 31iA
Machine Location: Korea
